Q: What is the difference between a self-propelled and a semi-electric mast lift?

The self-propelled AM series drives and can be operated at full height without outrigger setup, suited to facilities needing quick repositioning. The semi-electric MEWP series is manually moved between locations and uses outriggers for stability, reaching greater heights at a lower machine cost.

Q: Which platform should I choose for confined-space maintenance work?

For occasional maintenance tasks where the platform is set up once and used at height, the outrigger-stabilized MEWP series offers a lower-cost option with greater reach. For facilities requiring frequent repositioning across a wide floor area, the self-propelled AM series avoids repeated outrigger setup.

Q: Do I need outriggers to operate these platforms?

The MEWP series requires outrigger deployment for stable operation at height. The AM series does not use outriggers, relying instead on its low center of gravity and small turning radius.

Q: How high can these single-mast lift platforms reach?

The AM series reaches a maximum working height of 8,000~9,500 mm depending on model. The MEWP series reaches 9,500~14,000 mm across its four models. See the Model Dimensions tables above for exact figures.

Q: What is the safe working load for the MEWP series?

Safe working load ranges from 136 kg to 150 kg depending on the model — see the Model Dimensions table above.

Q: Can the platform be driven while fully elevated?

The AM series is drivable at full height. The MEWP series is designed for manual positioning followed by electro-hydraulic lifting, rather than driving while elevated.

Q: What happens if the platform loses power while elevated?

The AM series includes an emergency lowering system and emergency stop button. Contact us to confirm the specific emergency-descent mechanism for a given MEWP model.

Q: What safety features are built into these platforms?

The AM series includes automatic pothole protection, an automatic brake system, an onboard diagnostic system, and anti-tilt alarms. Outrigger deployment on the MEWP series is itself a core stability feature at greater heights.

Q: Is operator training required?

Requirements vary by country and workplace safety regulation. We recommend confirming local operator training and certification requirements with your safety compliance team before deployment.

Q: Are these platforms available in different height configurations?

Yes. The AM series offers two height tiers (AM-S06, AM-S75), and the MEWP series offers four height tiers from 9,500 mm to 14,000 mm maximum working height.

WIZPLUS aluminum alloy lifting platforms provide safe, lightweight, and reliable aerial access solutions for indoor maintenance, warehouse operations, retail environments, and commercial facilities. Built for easy maneuverability and long-term durability, they are ideal for distributors, rental companies, and industrial users worldwide.

Request for a service

WIZPLUS Self Propelled Single-Mast Lift

Self Propelled Vertical Mast Lift Overview

The AM-Series self-propelled single-mast lift platform is constructed from a high-strength aluminum alloy, offering a structure that is both lightweight and highly rigid. Powered by an energy-efficient electric drive system, it delivers quiet, zero-emission performance, making it the perfect solution for warehouses, logistics centers, shopping malls, and factories.

Effortless Access in Confined Spaces

With an ultra-compact 800mm × 1500mm footprint and zero-turn radius, it effortlessly navigates narrow aisles and tight job sites.

Continuous Productivity at Height

Drivable at full height, it eliminates the need to lower the platform between tasks, slashing cycle times and boosting efficiency.

Eco-Friendly & Floor-Safe

The quiet, zero-emission electric drive is ideal for sensitive indoor environments, while standard non-marking tyres protect expensive commercial floors.

Model

AM-S06

AM-S75

Video Showcase

Self Propelled Vertical Mast Lift Overview

Effortless Access in Confined Spaces

With an ultra-compact 800mm × 1500mm footprint and zero-turn radius, it effortlessly navigates narrow aisles and tight job sites.

Continuous Productivity at Height

Drivable at full height, it eliminates the need to lower the platform between tasks, slashing cycle times and boosting efficiency.

Eco-Friendly & Floor-Safe

The quiet, zero-emission electric drive is ideal for sensitive indoor environments, while standard non-marking tyres protect expensive commercial floors.

Model

AM-S06

AM-S75

Video Showcase

WIZPLUS Semi-Electric Tilt-Able Single Mast Lift Platform

Veritcal Lift Platform Overview

WIZPLUS's semi-electric single mast lift series delivers safe, compact vertical access — with four models spanning 9.5m to 14m working height, combining manual maneuverability with electro-hydraulic lifting for maintenance, warehousing, and facility tasks in tight spaces.

Reach Without Compromise on Portability

Reaches up to 14m yet folds down to under 2.8m with a footprint as narrow as 750mm — easy to maneuver, transport, and store.

Layered Safety at Every Stage of the Lift

A self-locking gate, emergency lowering, horse burst protection, and an emergency stop button protect operators throughout the lift, backed by a strobe light and buzzer for visibility.

Reliable Power for Extended Use

AC and DC motor options, plus a charging indicator and protection system, keep the platform job-ready across long shifts with minimal downtime.

Models

MEWP-9575

MEWP-1109Y

MEWP-1210Y

MEWP-1412Y

Video Showcase

WIZPLUS Electric Single Mast Lift Platform

Veritcal Lift Platform Overview

Reach Without Compromise on Portability

Reaches up to 14m yet folds down to under 2.8m with a footprint as narrow as 750mm — easy to maneuver, transport, and store.

Layered Safety at Every Stage of the Lift

A self-locking gate, emergency lowering, horse burst protection, and an emergency stop button protect operators throughout the lift, backed by a strobe light and buzzer for visibility.

Reliable Power for Extended Use

AC and DC motor options, plus a charging indicator and protection system, keep the platform job-ready across long shifts with minimal downtime.

Models

MEWP-9575

MEWP-1109Y

MEWP-1210Y

MEWP-1412Y

Video Showcase

Veritcal Lift Platform Overview

Reach Without Compromise on Portability

Reaches up to 14m yet folds down to under 2.8m with a footprint as narrow as 750mm — easy to maneuver, transport, and store.

Layered Safety at Every Stage of the Lift

A self-locking gate, emergency lowering, horse burst protection, and an emergency stop button protect operators throughout the lift, backed by a strobe light and buzzer for visibility.

Reliable Power for Extended Use

AC and DC motor options, plus a charging indicator and protection system, keep the platform job-ready across long shifts with minimal downtime.

Models

MEWP-9575

MEWP-1109Y

MEWP-1210Y

MEWP-1412Y

Video Showcase

Choose the Right Vertical Mast Lifts for Your Warehouse

Dimensions

AM Series (Self-Propelled)

MEWP Series (Semi-Electric Tilt-Able)

Travel

Self-Propelled, Drivable at Full Height

Manual Travel, Electro-Hydraulic Lift

Stability

Small Turning Radius, No Outriggers

Outrigger-Stabilized

Max Working Height

8,000–9,500 mm

9,500–14,000 mm

Max Platform Height

6,000–7,500 mm

7,500–12,000 mm

Safe Working Load

—

136–150 kg

Machine Weight

1,100–1,350 kg

430–600 kg

Best For

Continuous-use facilities needing fast repositioning (malls, airports, warehouses)

Confined-space maintenance work needing greater height at lower cost

Application Scenarios AM Series

Designed for warehouses, factories, shopping malls, and airports with narrow passages and complex working environments requiring a small turning radius.

How WIZPLUS AM Series Works

Built with a high-strength aluminum alloy mast, this platform combines lightweight design, rigidity, and durability. Its compact structure enables easy maneuverability in narrow spaces, while the electric drive system delivers efficient, quiet, and zero-emission operation with reliable safety protection.

Why This Solution Fits

No outrigger setup, combined with full self-propulsion and drivable-at-full-height operation, reduces repositioning time in facilities with continuous foot or vehicle traffic — such as malls and airports — where footprint and setup speed matter.

Application Scenarios MEWP Series

Ideal for maintenance, warehousing, and facility management operations requiring compact access solutions in confined spaces and narrow aisles.

How WIZPLUS MEWP Series Works

This platform combines manual maneuverability with electro-hydraulic lifting. A high-strength aluminum alloy mast provides stability, durability, and lightweight performance, while the tilt-able design and outriggers extend stable working height across a taller range than the self-propelled AM series.

Why This Solution Fits

The outrigger-stabilized design and four-model height range up to 14 m give facilities a lower-cost route to greater reach without self-propulsion drivetrain cost, suited to occasional confined-space maintenance tasks rather than continuous repositioning.
